2 mW CATV RF Over Fiber Tx 45-870 MHz
RF over Fiber Tx - 2mW Output 45-870 MHz
1310nm - 2mW fiber optic transmitter for television RF (radio frequencies) from 45-870 MHz. Directly converts any incoming RF signal within this band to optical RF. Transports all channels and programs over one fiber. Can be used for point-to-point applications, or combined with PLC couplers and fiber optic splitters for point-to-multipoint applications. Outputs industry-standard RFoG (RF over Glass) signals that can be accepted by most fiber optic RF receivers from other manufacturers. The easy-to-read front panel LCD provides information and alarm data, and simplifies configuration. This system features a highly linear DFB laser with automatic adjustment circuitry with Automatic Gain Control. For added reliability, a second internal Power Supply Unit is available as an option.
The transmitter can be used with any Thor Fiber optical RF receiver.
- 2 mW optical power output from a sensor feedback-controlled laser system
- Transports entire 45-870 MHz band even with full channel lineups
- Creates high-security "Fiber Breaks" to eliminate the coax signal return path
- Automatic Gain Control (AGC) manages RF level with no adjustment needed
- Compatible with all Thor RFoG CATV series optical receiver systems
- Coax-over-fiber extender
| *All Specifications Subject to Change Without Notice | |||
|
1x Type-F connector - 75 Ohm |
||
|
1310 nm | ||
|
< 1 MHz FWHM | ||
|
>20 dB XP | ||
|
< -160 dB/Hz | ||
|
2 mW (+2 - 0dBm) | ||
|
>55 dB | ||
|
SC/APC - Angle Polished FC-APC - Optional |
||
|
11-29 dBmV AGC Managed | ||
|
<+/- 0.75 45 - 862 MHz | ||
|
>17 dBm | ||
|
>50 dB @ 10km fiber length | ||
|
< -63 dB | ||
|
< -57 dB | ||
|
19 x 10 x 1.75 inch | ||
|
2.5 kg | ||
|
0 - 45 ? | ||
